OEM Vacuum Induction Furnace , Horizontal Industrial Vacuum Oven 2T-35T
Industrial sintering furnace is applied for powder metallurgy, such as stainless steel sintering (injection and silk screen) and magnetic material, such as aluminumalnico and samarium cobalt.
| Name | Parameter |
| Vacuum sintering furnace | sintering process, debinding, dewaxing |
| Model | Horizontal, Vertical |
| Ultimate vacuum | Custom made |
| Pressure rising rate | 0.5pa/h |
| Max temperature | Custom made |
| Temperature uniformity | ±3℃ / ±5℃ |
| Heating power | Custom made |
| Temperature control method | Intelligent programmable temp controller |
| Control method | PLC auto/manual interlock protection |
| Max gas charging pressure (absolute pressure) | Custom made |
| Main technical data of 1450 degree vacuum sintering furnace | ||||
Effective working | Max temperature | Ultimate pressure | Pressure | Temperature |
| 600x500x1200 | 1450 | 2x10-3 | 0.5 | ±3 |
| 800x300x1200 | 1450 | 2x10-3 | 0.5 | ±3 |
| 800x800x1200 | 1450 | 2x10-3 | 0.5 | ±3 |
| 900x900x1500 | 1450 | 2x10-3 | 0.5 | ±3 |
| custom made | 1450 | custom made | custom made | custom made |
